| Product Parameter |
| Model |
G4 |
| Packing info |
Packing Size |
1320*265*590mm |
| G.W |
43+/-1KG |
| Product basic parameter |
Expand scooter size |
1336*1295*660MM |
| Fold scooter size |
1336*550*660MM |
| N.W |
37+/-1KG |
| Handlebar width |
660MM |
| chassis height |
185MM |
| Pedal size |
220MM*510MM |
| Max load |
120KG |
| Waterproof level |
IPX4 |
| Frame material |
Steel+aluminum hybrid frame |
| Speed KM/H（Load 65kg） |
1st gear |
20KM/H |
| 2nd gear |
40KM/H |
| 3rd gear |
No limit speed（Full power with load 65KG on flat road，maxium speed70km/h） |
| 4th gear |
Non |
| Brake system(disc brake，e-brake，others) |
Front and rear dual disc brake |
| Climbing degree |
20° |
| Maxium mileage |
75km（Eco mode load 65kg flat road uniform speed） |
| Brake distance M |
Dry brake, speed 15km/h, braking distance ≤ 4 M |
| Maxium speed（idling） |
99km/h（idling） |
|
|
|
|
| Motor |
Brand |
KuKirin |
| Rated power |
2000W |
| Voltage |
60V |
| Instantaneous maximum power |
Limiting 40A≥2400W |
| Maxium rotate speed |
1350±30rpm |
| Maximum output torque |
Limiting 45A≥38N.m |
| Accelerate mode(sine wave/square wave/) |
sine wave |
| Motor type（integrated, split, other in-wheel motors) |
integrated motor |
|
|
|
|
| Battery |
Capacity |
20Ah |
| Voltage |
60V |
| Charging time |
10~12 hours |
| Battery protect system |
|
| Standard power consumption (KW.H) |
1.2KW.H |
| Brand |
KuKirin |
|
|
|
|
| LED Headlight |
Number of lamp beads |
3 |
| Power(Watt) |
3w |
| Irradiation angle |
60 degree |
| Irradiation area |
— |
|
|
|
|
| Charger parameter |
Input voltage |
100~240V |
| Input current |
2A |
| Output voltage |
67.2V |
| Output current |
2A |
|
|
|
|
| Inner tube |
Size |
— |
| Type |
— |
| Material |
— |
| Brand |
— |
|
|
|
|
| Tire |
Size |
11吋（90/65-6.5） |
| Type |
Vacuum tire |
| Best tire pressure |
350kpa（50p.s.i） |
| MAX.LOAD |
190KG(418LBS) |
| Material |
Rubber |
| Brand |
— |
|
|
|
|
| Seat cushion |
Lowest(height from ground) |
|
Non |
| Highest(height from ground) |
|
Non |
|
|
|
|
| Disc brake |
Brand |
— |
| outer diameter |
140MM |
| Thread inner diameter |
33.3MM |
|
|
|
|
| Instrument |
Type(LED/LCD/OLED) |
LED |
| Size |
155*55mm |
| display content |
Speed/Power/Mileage/Cruise control/speed mode/Start mode/Light mode/Mileage unit mode |
| Function setting |
Mileage unit mode/Speed unit/Speed mode/Start mode/Light mode |
|
|
|
|
| APP |
General(note general with which model) |
/ |
|
|
|
|
| Function description |
Cruise control function |
Yes (long press mode to turn on/off cruise control) |
| KM/H setting to MPH/MILE |
Yes (click “set” to switch between speed and mileage units) |
| Cancel the limit speed |
Yes (press and hold the brake lever, turn on and off the single machine four times in a row) |
| Non-zero start/Zern start |
Yes (long press “set” to switch non-zero start/zero start) |
|
|
|
|
| Packing list |
Charger,User manual,Tool bag,Rear fender |
